TiviMate Recording Guide (2026): How to Record Live TV with DVR

Overview

TiviMate recording is a premium feature that includes a full-featured DVR system. It lets you record live IPTV channels, schedule recordings from the electronic program guide, and watch recordings on any device. This guide covers everything from setup to advanced recording management.

TiviMate Recording Quick Start

If you just want to record the current channel immediately:

1. Press OK/Select on your remote while watching a live channel.
2. Navigate to Menu > Record.
3. Select Record Current Program for the full remaining duration, or choose Custom to set a specific end time.
4. The red recording indicator appears at the top of the screen confirming the recording is active.

That is all it takes. But TiviMate’s recording capabilities go far deeper. The sections below cover scheduled recordings, storage configuration, background recording, and advanced management.

Requirements for TiviMate Recording Setup

Before you can record, ensure your setup meets these requirements:

• TiviMate Premium subscription — recording is a Premium-only feature. The free version does not include DVR functionality.
• Storage device — internal storage works, but an external USB drive is recommended for longer recordings.
• Live channel availability — you can only record actively available live channels. You cannot record VOD content.
• EPG data — scheduled recordings from the guide require accurate EPG information for your channels.
• Sufficient storage space — recordings consume significant space, especially at higher qualities.

Storage Requirements and Setup

Recording Sizes by Quality

Recommended Storage Capacities

Setting Up Storage for Recordings

Internal Storage

TiviMate can save recordings directly to your device’s internal storage. This works well for short recordings but fills up quickly. On Firestick devices with only 8 GB of total storage, you may only have 4-5 GB available after system files and apps — enough for approximately 2 hours of HD recording.

External USB Drive

For serious recording, a USB drive is essential. Follow these steps:

1. Format your USB drive as FAT32 or exFAT (NTFS is not recommended for TiviMate).
2. Connect the drive to your streaming device via USB OTG cable or USB hub (for Firestick, use a powered USB hub or OTG cable with external power).
3. On Firestick: the drive may not auto-mount. Install a file manager app to verify the drive is detected.
4. Open TiviMate > Settings > Recording > Recording Storage.
5. Select your USB drive from the list. If it does not appear, try reconnecting the drive or restarting TiviMate.
6. Create a dedicated folder for TiviMate recordings to keep files organized.

USB Connection by Device

Schedule TiviMate Recordings from the EPG

Scheduling recordings from the program guide lets you record future shows without manual intervention:

1. Open the EPG by pressing the OK/Select button and navigating to the Guide view.
2. Long-press (press and hold) on any future program in the guide.
3. Select Schedule Recording from the context menu.
4. Choose Record this episode (one-time) or Record series (recurring).
5. Optionally adjust Start earlier and End later padding (recommended: 2-5 minutes each side to avoid missing content).
6. Confirm — the program now shows a red recording icon in the EPG.

To view all scheduled recordings, go to Settings > Recording > Scheduled Recordings.

Background Recording — Watch While You Record

TiviMate supports background recording. When a recording is active, you can change channels freely — the recording continues unaffected in the background. This allows you to:

• Record one channel while watching another live.
• Start a recording, switch to a different program, and come back to the recorded content later.
• Set up multiple scheduled recordings and watch any channel during the recording window.

The only limitation is your device’s hardware. Devices with less than 2 GB of RAM may struggle with simultaneous playback and recording, especially for HD streams.

Managing Your Recordings

Access all your recordings from the main menu by navigating to Recordings. From this screen you can:

• Play any recording directly within TiviMate.
• Delete recordings to free up space.
• Rename recordings for easier identification.
• View recording details (date, duration, file size, channel).

How Many Recordings Can Run at Once?

The actual limit depends on your IPTV provider’s server capacity and your internet connection speed. Each recording stream consumes bandwidth independently.

Recording File Format and Playback

TiviMate records in the .ts (MPEG-TS) format — a standard Transport Stream container. Key characteristics:

• No DRM or encryption — recordings are standard TS files playable on any device.
• 4 GB file segmentation — long recordings are split into 4 GB segments (FAT32 file size limit). TiviMate handles playback seamlessly across segments.
• VLC-compatible — you can copy TS files to a computer and play them in VLC, Kodi, or any media player that supports the format.
• Metadata preserved — channel name, program title, and recording date/time are embedded in the file metadata.

TiviMate DVR vs Alternatives

TiviMate offers the best value-for-money DVR solution in IPTV. While Channels DVR and Plex Pass offer more robust server-based recording (especially for multi-room setups), their annual cost is 12-19 times higher. For a single-home setup with one or two devices, TiviMate’s DVR is more than sufficient.

Troubleshooting TiviMate Recordings

Frequently Asked Questions
